System Arwyddion Rheoli Clyfar
Manylion
System reoli jamio ffôn symudol sy'n dal dŵr
Model: AAT-SMART-J2
Dosbarthiad cynnyrch
System Jamio Smart
Share to
Disgrifiad

Cyflwyniad Cynnyrch

The system for entering the prison or for the mobile operator communication system has special requirements of that user terminal in the communication coverage area, according to the user's classification, communication permission or communication blocking. For special target users, according to communication system difference, it is also possible to conduct further communication checks.

Mae'r system rheoli cyfathrebu yn cynnwys y system gyfathrebu ganlynol: CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, 3G WCDMA, 4G LTE ac yn y blaen signal cyfathrebu symudol.

Gellir addasu'r system gyfan yn unol â gofynion cwsmeriaid penodol, a gall fodloni gofynion system gyfathrebu arbennig cyfuniad o wahanol wledydd neu ranbarthau yn hyblyg.


Mae swyddogaethau sylfaenol y system yn cynnwys:

● According to different communication system of in all coverage areas to terminal uers IMSI capture

● To captured IMSI filtering whitelist and blacklist

● Whitelist users release back to the macro network for normal communication.

● Not Whitelist user communication blocking and shielding

● Conduct communication monitoring for blacklist users who meet certain conditions, Or with other device for positioning

● 20W coverage distance directional antenna jamming diameter 1000-2000M, omnidirectional antenna jamming radius 500-800M.

● The detailed functions of the various communication systems included: Macro network scanning, Automatic and manual network settings, IMSI / ESN capture, Black and white list setting and filtering, Access policy configuration, In the network UE status monitoring, Report terminal signal strength.

● For TDD-LTE and FDD-LTE, the captured UEcan be redirected to the specified 2G and 3G systems.

Waterpoof signal jammer

Manyleb Cynnyrch

Band amledd gweithio

CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, 3G WCDMA, 4G LTE ac ati

Gallu

Ton cludwr uchaf ffrâm blwch uned: 4

Perfformiad

Pŵer allbwn RF uchaf: 40dBm / Band, Allbwn ffrwd sengl

Power adjustment range 0-30dB, adjustment step size 1dB, adjustment error±0.5dB

Cywirdeb cysoni: 0.1ppm

Pellter jamio

Diamedr jamio antena cyfeiriadol 20W 1000-2000M, radiws antena omnicyfeiriad 500-800M

Perfformiad WiFi

Cefnogi stêm sengl 2.4G

Pŵer 20dBm

Cefnogaeth 802.11b/g/n

Porthladd

RJ451(WAN) Cefnogaeth ar gyfer mynediad lleol

N-J2

2 RF port(ANT0,ANT1)

SMA-J

Antenaport WiFi (safonol), Cefnogaeth ar gyfer mynediad lleol

SCAN Antena Cydamseru

porthladd GPSantenna

Cysoni amser

Cefnogaeth fesul band cysoni amser GPS

Cefnogi amser gweinydd NTP cysoni, fesul band

Dal perfformiad rhif

Cyfradd dal terfynell statig segur Yn fwy na neu'n hafal i 95 y cant, Cyfradd nifer dal terfynell symudol Yn fwy na neu'n hafal i 90 y cant

Jamio cyfathrebu

Cysylltiad diwifr meddalwedd, jamio gwyrdd

Rhestr wen

Cefnogi defnyddwyr rhestr wen i ryddhau cyfathrebu arferol i'r rhwydwaith cyhoeddus

Gosodiadau polisi defnyddiwr

Cefnogi gwthio 4G/3G/2G yn ddewisol

Amser cychwyn system

Llai na neu'n hafal i 300s

Defnydd mwyaf

4 box frame total consumption >1000W

Dimensiwn


Pwysau


Deunydd

alwminiwm

Lefel Amddiffyn

IP32/IP65 dewisol

Lliw

Du

Pwer

AC220

Gofynion amgylcheddol

Indoor environment,-30 degree -55 degree ,humidity<85%


Os oes angen mwy o wybodaeth arnoch, anfonwch e-bost atom.
